PTQ18 Photoelectric Switch
FEATURES

T-shaped housing design, saving space.

N.O./N.C.function swithable by different wires.

Easy to install.(30*45.9*31.9mm)

Special design for bending resistance.

Superior waterproof IP67

SEND US YOUR MESSAGE
Video
Main Technical Parameters
Model NPN L.on/D.on PTQ18-DU10/40N PTQ18-DU10/40NK1
PNP L.on/D.on PTQ18-DU10/40P PTQ18-DU10/40PK1
Sensing type Diffuse reflection
Sensing distance 10cm/40cm, white paper 10*10(10/40cm)
Emitting light lnfrared LED 850nm
Operating voltage DC12~24V
Current Consumption 20mA Max
Load current 100mA Max.at DC20V
Response time 1.5ms Max.
lnsulation resistance 20MΩmin.(DC500V)
Voltage withstandabiligy AC1000V 60Hz for 60 Sec
Operating temperature -25℃~+60℃
Ambient humidity 35%~85%RH
Protection degree IP67
Material ABS
Wiring method M12 plug-in connector type Pre-wiredΦ4.2*2M/3-wires
Weight Approx.68.5g Approx.18g



Dimensions
