Universal type with 8-shaped rotated adjusting knob to do micro-adjustment
Double detection distance of traditional product
With a variable knob
With pulsing light to respond within an ultra-short time of 20
Can detect delicate aberration with green light source
| Project | General-purpose NPN output | Model: E3X-A11 |
| light source(ight-emitting wavelength) | Red light-emitting diode(660nm) | |
| Voltage | DC10~30v [with the pulse (p-p)10%] | |
| Current consumption | The following 35mA | |
| Output Control | Main voltage of load is below DC35v, load current is below 100mA (residual voltage below lv), open-collector output type (NPN or PNP output varies in different state), on when | |
| Response time | Reset action，the following 200us | |
| Sensitivity adjustment | 8 rotary knob without end(with indicator) | |
| Protection circuit | Protection against the power connection ,output short circuit protection to prevent interference function | |
| Lighting | Smooth by the light ,incandescent 3000rx below ,following the sun 10000rx | |
| Ambient temperature | When action: -25~+55℃, save time:40~70℃ (there can not be frozen, the phenomenon of condensation) | |
| Surrounding humidity | 35~85%RH, Save: Save time: 35~95%RH (can not have the phenomenon of condensation) | |
| Insulation resistance | 20mΩ above (DC500MV to trillion dollars) | |
| Voltage resistance | AC1,000V 50/60Hz 1min | |
| Vibration (durable) | 10~55Hz complex amplitude l.5mm X, Y, Z direction of the 2h | |
| Shock (durable) | 500/s2 X.Y.Z direction of the 3rd | |
| Protection structure | IBC standard IP50 (when the installation of protective cover) | |
| Connection | Open-wire lead (standard long line 2m) | |
| Weight (in cases) | 100g | |
| Materials | Shell | Heat-resistant ABS |
| The protective shield | Polyester | |
| Accessories | The installation of metal accessories used to adjust screwdriver, operation manuals | |
